BSTPL-56R, is a basic Tracking Device made with combination of 2G GSM and GNSS technologies. Built with most advanced Microprocessor, BSTPL-56R provides additional interfaces to customers with RS-485, Bluetooth 4.0*, One Digital Input, One Analog Input, One Digital Output, One SoS Interface, 3 Axis Accelerometer and 1 Wire Interface.

With built-in high quality 2G GSM Module, BSTPL-56R supports Quad Band 2G GSM networks operating on 850/900/1800/1900 MHz frequency and supports Class 12 GPRS. Highly sensitivity GNSS module with 33 Tracking and 99 Acquision Channels with -167 dBm gain provides accurate location data in toughest and difficult conditions.

Easy to install, BSTPL-56R provides highly reliable and accurate data to customers like Location Information, Speed, Direction, GPS Odometer, Alerts and Other IOʼs related information. Supporting wide operating voltage of 7V to 100V DC, BSTPL-56R has provision for 3.7V Li-Ion internal battery with built-in charging circuit and uses a rugged Nylon enclosure meeting IP65 standard with built in GSM, GNSS and Bluetooth* antennas. BSTPL-56R supports SIM interface of both eSIM and Micro SIM.

BSTPL-56R provides various alerts related to vehicle like Main Power Connection / Disconnection, Ignition ON/OFF, SoS Status, Over Speeding, Harsh Breaking, Harsh Acceleration, Harsh Maneuver and Box Open / Close conditions. BSTPL-56R hardware is designed with low power consumption for long battery backup. This will also minimise the draining of vehicle battery when the vehicle is idle for long time. BSTPL-56R also supports Sleep Mode feature which reduces the power consumption to less than 10 mA.
