BSTPL-17L 4G LTE GPS Device

Download Brochure download

BSTPL-17L is an advanced vehicle tracking device complying to newly introduced intelligent transport system standards, AIS-140 & IS 16833:2018. BSTPL-17L Designed for complying to standards like IS 9000, ISO 16750, AIS 004, IEC 60529, IS 2465, ISO 6722 and ISO 7637. In addition to fulfilling the functionality requirements as required by AIS-140, the device meets interface requirements like multiple IO Ports, SOS (Emergency Button), RS-232 interface, Bluetooth and CAN Interface.

Considering the mandate of government of India to have vehicle tracking device with one or more emergency buttons in all existing and new public service vehicles complying to AIS140 standard, BSTPL-17L is designed keeping in view the Indian operating conditions. Software functionalities are built to integrate the device with the governments command center and send emergency alerts as mandated in the regulation.

BSTPL-17L is equipped with advanced high-speed microprocessor and microcontroller supported by highly sensitive IRNSS/GNSS Receiver and 4G LTE Transceiver supporting automatic fall back to 2G and vice versa. With built-in high quality 4G LTE module, BSTPL-17L supports 4G LTE Bands B1/B3/B5/B7/B8/B20/B28/B38/B40/B41 and 2G GSM networks operating on 850/900/1800/1900 MHz frequencies. With Internal GSM, IRNSS and GNSS Antennas, BSTPL-17L delivers accurate real time data in toughest environmental and operating conditions. Compact in size, BSTPL-17L enables easy handling and easy installation. In addition to external memory, device is also provisioned with eMMC chip which can support up to 64 GB memory.

Supporting four different types of protocols, device has provision for generating alerts for Emergency Button, Box Tamper, Ignition On/Off, Vehicle Battery Connect / Disconnect, Internal Battery Low, Harsh Breaking, Harsh Acceleration and Harsh Maneuver. Operates on wide DC operating voltage range of 7-100V, BSTPL-17L is recommended for vehicles which operates on 12/24V battery and Electric Vehicles which operates on extended operating voltage i.e. up to 100V. BSTPL-17L is also provided with internal battery for continuous operation when main power is disconnected or tampered.

  • Advanced High-Speed Microprocessor & ARM Cortex Microcontroller
  • 50000 Data Packets Storage. Expandable to 100000 Data Packets. Provision for 64GB eMMC Chip
  • Supports 4G LTE Bands: B1/B3/B5/B7/B8/B20/ B28/B38/B40/B41 & Quad Band GSM
  • Auto fall back from 4G to 2G & 2G to 4G.
  • Supports SMS; TCP/IP; FTP, HTTP, HTTPS & MQTT & MQTTS Communication Protocols*
  • Internal GSM Antenna Supporting 4G and 2G
  • Supports Nano SIM Card and dual profile eSIM
  • Supports IRNSS, GPS & GLONASS
  • 33 Tracking and 99 Acquision channels with -167 dBm Sensitivity
  • Horizontal Position Accuracy of <3 meters CEP @ -130 dBm (Open to sky)
  • Built in Embedded IRNSS & GNSS Antennas
  • Provision for Bluetooth 4.0 with built in antenna
  • Five Digital Inputs & Two Analog Inputs
  • Two Digital Outputs & One SOS Interface
  • Wide DC Input Operating Voltage (7V to 100V)
  • Main Power Reverse connection protection
  • Main Power Over Voltage protection
  • 3.7V Internal Li-Ion Battery
  • Main Power Voltage Reading
  • 3 Axis Accelero & Gyrometer
  • LED indication for Main Power, Internal Battery, GSM and IRNSS/GNSS Networks
  • Box Open / Close detection
  • Main Power Connect / Disconnect Alert
  • GPS Odometer
  • Sleep Mode function for extended internal battery backup time
  • Nylon Plastic Enclosure complying to IP67
  • Complies With IECXEx Standards
  • Local and Over The Air (FOTA) Software Update
  • Local and Over The Air (OTA) Configuration
  • Secured Over The Air (OTA) Configuration
  • 16 Core Cable
  • Provision For Two RS-232 Interfaces
Microprocessor Advanced High Speed Processor, 1MB Program Memory & 2MB RAM
Micro-controller 32-bit Cortex M3 Microcontroller, 256 kB Program Memory and 12-bit ADC
Internal Memory 64 Mb. Supports 45000 Data Packets Storage When No GSM/GPRS Network 100K Erase & Program Cycles. 20 Years Data Retention, Expandable to 128 Mb. Provision for 64GM eMMC for GNSS based toll system
Power Supply Wide Range Of Operating Voltage. DC 7 - 100V
Internal Battery 3.6V, 1000 mA Li-Ion Battery. Expandable to 2000 mA
4G LTE GSM CAT1, 4G B1/B3/B5/B7/B8/B20/B28/B38/ B40 /B41 and Quad Band GSM Sensitivity: -109dBm. Auto fall back from 4G to 2G & 2G to 4G.
IRNSS & GPS Supports IRNSS, GPS & GLONASS 33 Tracking and 99 Acquision channels, -167 dBm Sensitivity, Horizontal Position Accuracy of <3 meters CEP @ -130 dBm (Open to sky)
SIM Support Supports eSIM with Automatic Profile Switching. Optional Nano Plastic SIM
Communication Protocols TCP/IP, HTTP, HTTPS, FTP, MQTT & MQTTS
Input & Output Ports 4 Digital Inputs, 2 Analog Inputs, 2 Digital Outputs, 2 RS232 Ports, 1 CAN Interface*, 1 SOS Interface & Bluetooth 4.0
Sensors 3 Axis Accelero & Gyrometer. Box Open / Close Sensor
External Interfaces Supports Fuel & Temperature Sensors, RF & NFC Reader and Immobilization Function
Antennas Internal GSM & GNSS + IRNSS Antennas
Mechanical Nylon Plastic Enclosure complying to IP67. Dimensions: 118 x 77 x 31 mm
Environmental Operating Temperature: -25°C to +85°C Storage Temperature: -40°C to +85°C Humidity: 95% Non-Condensing
LED Indications Main Power, Internal Battery, GSM Network & GNSS Status
Configuration Local and Over The Air (OTA) Configuration. Supports SMS & GPRS Modes Local and Firmware Over The Air (FOTA) Support
Standards Complying IS 9000, ISO 16750, AIS 004, IEC 60529, IS 2465, ISO 6722, ISO 7637 and IP67 IS 16833:2018
Protections Main Power Over Voltage, Reverse Connection & Tamper Detection. ESD Protection
Alerts Main Power Connect/Disconnect, Device Tamper, Over Speed, Harsh Breaking, Harsh Acceleration and Harsh Turning
Image 1
Image 3
Image 2
Image 4
Alerts For:
  • Box Opening / Closing
  • Vehicle Battery Connection / Disconnection
  • Ignition On / Off
  • Digital Inputs & Digital Output
  • SoS Activity
  • Internal Battery Low
  • Over Speed
  • Harsh Breaking
  • Harsh Acceleration
  • Harsh Turning
