BSTPL-56L, is a basic Telematics Device made with combination of 4G LTE and GNSS technologies. Built with most advanced Microprocessor, BSTPL-56L provides additional interfaces to customers with CAN, One Digital Input, One Digital Output, One Analog Input, One SOS Interface and 3 Axis Accelerometer. Supporting wide operating voltage range of 7-100V DC, BSTPL-56L includes features like location information, speed, direction, GPS odometer, driving behaviours, data from the interfaces integrated with vehicle like Battery SOC & SOH, Vehicle Diagnostics, Battery Health, Individual Cell Voltages, Cell Temperatures and many more.

With built-in high quality GSM Module, BSTPL-56L supports 4G LTE Bands B1/B3/B5/B7/B8/B20/ B28/B38/B40/B41 bands. Highly sensitive GNSS module with 33 Tracking and 99 Acquision Channels with -167 dBm gain provides accurate location data in toughest and difficult conditions.

BSTPL-56L is recommended for vehicles which operates on 12/24V battery and Electric Vehicles which operates on extended operating voltage i.e. up to 100V. BSTPL-56L is also provided with internal battery for continuous operation when main power is disconnected or tampered. BSTPL-56L uses a rugged Nylon enclosure meeting IP65 standard with built in GSM and GPS antennas. BSTPL-56L supports SIM interface of both eSIM and Micro SIM.

Capable of supporting different types of protocols, BSTPL-56L provides various alerts related to vehicle like Main Power Connection / Disconnection, Ignition ON/OFF, SoS Status, Over Speeding, Harsh Breaking, Harsh Acceleration, Harsh Maneuver and Box Open / Close conditions. BSTPL-56L hardware is designed with low power consumption for long battery backup. This will also minimise the draining of vehicle battery when the vehicle is idle for long time. BSTPL-56L also supports Sleep Mode feature which reduces the power consumption considerably. Compact in size, BSTPL-56L enables easy handling and easy installation.
