• Box Opening / Closing
  • Main Power Connection / Disconnection
  • Digital Input
  • SoS Activity
  • Over Speed
  • Internal Battery Low
  • Harsh Breaking
  • Harsh Acceleration
  • Harsh Turning

BSTPL-15, is a basic Tracking Device made with combination of GSM/GPRS and GNSS technologies. Built with most advanced 32 Bit Cortex M0 Microcontroller, BSTPL-15 provides additional advantages to customers with One Digital Input, One Analog Input, One Digital Output, One SoS Interface and 3 Axis Accelerometer in addition to providing location details.

With built-in high quality GSM Module, BSTPL-15 supports all the 2G GSM networks operating on 850/900/1800/1900 MHz frequency and supports Class 12 GPRS. Highly sensitivity GNSS module with 33 Tracking and 99 Acquision Channels with -167 dBm gain provides accurate location data in toughest and difficult conditions.

Easy to install, BSTPL-15 provides highly reliable and accurate data to customers like Location Information, Speed, Direction, GPS Odometer, Alerts and Other IO’s related information. Supporting wide operating voltage (DC 7V to 36V), BSTPL-15 has provision for 3.7V Li-Ion internal battery with built-in charging mechanism and uses a rugged Nylon enclosure meeting IP65/67 standards with built in GSM and GPS antennas.

BSTPL-15 provides various alerts related to vehicle like Main Power Connection / Disconnection, Ignition ON/OFF, SoS Status, Over Speeding, Harsh Breaking, Harsh Acceleration, Harsh Turning and Box Open / Close conditions.

BSTPL-15 hardware is designed with low power consumption for long battery backup. This will also minimise the draining of vehicle battery when the vehicle is idle for long time. BSTPL-15 also supports Sleep Mode feature which reduces the power consumption to less than 10 mA.

  • Cortex M0; 32 Bit Microcontroller
  • 10000 Data Packets Storage*
  • Multi Slot Class 12 GSM / GPRS Modem
  • 33 Tracking & 99 Acquisition Channels GPS Receiver with -167 dBm gain
  • Supports A-GPS
  • 3 Axis Accelerometer
  • Local and Over The Air (OTA) Software Update
  • Local and Over The Air (OTA) Configuration
  • Secured Over The Air (OTA) Configuration
  • Supports TCP/IP; FTP; HTTP; HTTPS & MQTT Communication Protocols
  • GPS Odometer
  • Wide DC Input Operating Voltage (7V to 36V)
  • Main Power Reverse connection protection
  • Main Power Over Voltage protection
  • Built-In 3.7V Li-Ion Battery
  • Main Power Voltage Reading
  • Box Open / Close detection
  • Main Power Connect / Disconnect detection
  • GSM Internal Antenna
  • GPS Internal Antenna
  • Nylon Plastic Enclosure complying to IP65/67*
  • Configurable Data Sending Intervals
  • Dynamic Data Sending
  • LED Indication for Main Power; Internal Battery, GSM & GPS Status
  • Provision for 2 server IPs and Ports
  • Supports Sleep Mode function for longer battery backup
  • One Digital Input
  • One Digital Output
  • One Analog Input
  • One SoS Switch Interface
Microcontroller 32 bit Cortex M0 Microcontroller,
256 kB Program Memory and 12 bit ADC
Internal Memory 4 Mb. Supports 10000 Data Packets Storage When No GSM/GPRS Network
100K Erase & Program Cycles. 20 Years Data Retention Expandable to 64 Mb
Power Supply Wide Range Of Operating Voltage. DC 7 - 36V
Internal Battery 3.6V, 500 mA Li-Ion Battery. Expandable to 2000 mA
GSM Module Quad Band GSM 850 / 900 / 1800 / 1900 MHZ.
Sensitivity: -109 dBm. ; Class 12 GPRS. Coding Schemes: CS1 2 3 4.
Maximum UL & DL Speed: 85.6 kbps
GPS Module Supports GPS & GLONASS ; Also Supports GAGAN and AGPS
33 Tracking & 99 Acquision Channels. ; Sensitivity: -163 dBm
Horizontal Position Accuracy: 2 Meters ; CEP @ -130 dBm (Open to Sky)
SIM Support Supports eSIM With Automatic Profile Switching & Plastic SIM
Communication Protocols TCP/IP, HTTP, FTP & MQTT
Input & Output Ports 1 Digital Input, 1 Analog Input, 1 Digital Output & 1 SOS Interface
Sensors 3 Axis Accelerometer ; Box Open / Close Sensor
External Interfaces Immobilization, Analog Fuel and Temperature Sensors
Antennas Internal GSM & GNSS Antennas
Mechanical Nylon FR Enclosure, Complies to IP65/67*
Dimensions: 88 x 56 x 27 mm
Environmental Operating Temperature: -25°C to +85°C
Storage Temperature: -40°C to +85°C
Humidity: 95% Non-Condensing
LED Indications Main Power, Internal Battery, GSM Network & GNSS Status
Configuration & Firmware Local and Over The Air (OTA) Configuration & Supports SMS & GPRS Modes ;
Local and Firmware Over The Air (FOTA) Support
Protections Main Power Over Voltage, Reverse Connection & Tamper Detection
Power Requirements 7 - 36V DC ; 3.7V / 500 mA Li-Ion Battery
